EPCM & Integration · Detailed Engineering
Detailed Engineering & Design
Detailed engineering takes the approved FEED basis and develops it into the drawings, models, and specifications that fabrication and construction build from. Our multidiscipline teams cover process, mechanical, piping, structural, electrical, instrumentation, and controls, all coordinated in a single 3D model so clashes are caught on screen, not in the field. The output is a complete, reviewed deliverable set ready for procurement and the shop floor.
What you get
The shape of the deliverable.
Outcomes our customers see when this scope is on our floor. Specific, repeatable, and held against the same quality system across the company.
- Build-ready deliverables
- A coordinated, reviewed deliverable set that fabrication and field crews can build from without rework loops back to engineering.
- Clashes caught on screen
- Full 3D coordination across disciplines finds interferences in the model, where they cost hours to fix, not in the field where they cost weeks.
- Procurement-ready specs
- Datasheets and bills of material flow straight into purchasing, so long-lead items are ordered on time.
Scope
What this actually covers.
The specific work we deliver under Detailed Engineering & Design.
Scope 02
Mechanical, piping, and stress analysis
Scope 03
Structural and civil design
Scope 04
Electrical, instrumentation, and control system design
Scope 05
Equipment and instrument datasheets and specifications
Scope 06
Isometrics, bills of material, and construction drawings
How we work
Standards, scope, and where.
Codes & standards
- ASME B31.3 (process piping)
- ASME Section VIII Div. 1 (pressure equipment)
- ISO 9001 (quality management)
Industries
Where this lands.
Related capabilities
The in-house scope behind this service.
Need Detailed Engineering & Design?
Send the brief.
Drawings, datasheets, or just the problem. We respond promptly with a routing recommendation and an honest read on scope and schedule.
